Microboards HCL Autoloader with 4 or 8 drives

Microboards HCL Autoloader with 4 or 8 drives
(0 reviews)

SKU HCL-4000
Weight 250.00 lbs
Availability: 3 to 7 days
Our price:
Buy more to save!
Qty Price
1+ Item CAD$0.00
Blu-ray option
Qty Out of stock or special order.
Click here to subscribe for 'Back-in-stock' notifications
* Contact us for a price quote *

Microboards HCL Autoloader duplicators from 4 to 8 drives.

Includes pickup at our dock or delivery in Montreal area! (Truck dock or strong help required)

For unattended disc duplication runs, let the Microboards HCL Autoloader handle the work load. With a state-of-the-art robotic arm and eight drives, the autoloader will burn up to 56 CDs or 40 DVDs per hour.

  • Complete standalone operation: No PC required
  • Maximum 1000 disc capacity
  • Multi-Master Recognition Technology (MMRT): Loads multiple masters at once to run multiple duplication jobs in succession.
  • Sticky media separator option: Higher probability to separate sticky media.
  • Multi-Language capability for English & Spanish
  • Auto-Counter Technology: Displays the total number of discs successfully copied compared to desired output for each project.


Model: MICROBOARDS AUTOLOADER: 18x DVD/CD Autoloader, Stand-Alone
Disc Capacity
(Depends on Media Type)
1,000 Discs
Part Nos.

4 Drive CD/DVD: HCL-4000
(HCL-6000 discontinued)
8 Drive CD/DVD: HCL-8000
4 Drive Blu-ray: HCL-BD4000
6 Drive Blu-ray: HCL-BD6000
8 Drive Blu-ray: HCL-BD8000

Target 4, 6, & 8
Hard Drive Options: 160 GB
Throughput Capacity per Hr.
4 Drives: 20 DVD / 28 CD
6 Drives: 30 DVD / 42 CD
8 Drives: 40 DVD / 56 CD
Max Writing Speed 18X DVD+R, 18X DVD-R, 10X Double Layer DVD+R, 6X-10X Dual Layer DVD-R, 8X DVD+RW, 6X DVD-RW, 40-48X CD-R, 24X-32X CD-RW
Display 20 x 2 LCD
Buffer Memory 128 MB
Partition Naming Up to 8 characters per partition
Account Mgmt 32 users (standard) or 64 users (premium)
Auto Counter Up to 9,999 per title
DVD-ROM, DVD-Video, DVD-Audio, DVD+R DL, DVD-R DL, DVD-R, DVD-RW, DVD+R, DVD+RW, Mode 1: CD-ROM, CD-1, Multi-session CD, CD-Plus, 61mm business card CD-R,
3" mini CD-R, CD-ROM Data Mode 2
DVD+R DL, DVD-R DL, DVD+R, DVD+RW, DVD-R, DVD-RW, 61mm business card CD-R, 3 inch mini CD-R, Orange Book standard 74 min/80 min CD-R/RW
Burn Proof
Power Supply Input 90 ~ 240 AV, 500 WATT max
20% ~ 80%
Temperature Extremes 40 C (104 F) / 5 C (41 F)
Regulations FCC, CE
Weight Actual equipment weight: approx. 50 lbs. Shipping weight: approx. 250 lbs
Price includes Montreal pickup or delivery
